Video, Audio and PTZ Data on Fibre.



Our video products deliver crisp, clear, full-speed streaming video over Fibre-Optic. ADD video products has a proven reliability record with more than 10,000 links installed in the field. Available in single and multi-channel configurations. The addition of Audio and Contact closure cards provide total CCTV security solutions.





LLD801 Composite Video on Fibre Transmitter. Din Rail Mount!



Single channel video transmitter. Plastic Din Rail Mount housing. 12VDC or Optional Built in 220VAC Power Supply.

WORKS WITH



LLD802, LL803R

Brochure

User Manual

Application Note

Text Box:    LLD802        Composite Video on Fibre Receiver.	Wall or Din Rail Mount!



Single channel video receiver. Plastic Din Rail Mount housing. 12VDC or Optional Built in 220VAC Power Supply.

WORKS WITH



LL801, LLD801, LL803T

Brochure

User Manual

Application Note

Text Box:    LL803R__A  3 x Channel Composite Video on Fibre Receiver.	In Metal Box Free Standing.



3 x Channel video Receiver. In metal box with own 220VAC Power supply.

WORKS WITH



LL801, LLD801, LL803T

Brochure

User Manual

Application Note

Text Box: ANALOG VIDEO

LL800S__ 3U 19 Card Frame with one Power Supply.



3U 19 Card Frame with one 220VAC power supply. Suitable for CCTV Video/Voice/Data on Fibre system. Can accommodate 6 Cards. Can be expanded to 12 cards.

WORKS WITH



LL801, LL803T&R, LL8422, LL422, LL8023,LL807

Brochure

User Manual

Application Note

LL8002D__ 3U 19 Card Frame with two Power Supplies.



3U 19 Card Frame with two 220VAC power supplies. Suitable for CCTV Video/Voice/Data on Fibre system. Can accommodate 12 Cards.

WORKS WITH



LL801, LL803T&R, LL8422, LL422, LL8023,LL807

Brochure

User Manual

Application Note

Text Box: AUDIO

Audio can be sent over Fibre using our unique optic modulation technique. This produces noise free transmission of audio.



The audio range includes Microphone amplifiers and intercom interfaces and can be used in stand alone or in our MUX systems. Please see our selection below.

Products can be selected for Multi Mode or Single Mode Fibre.

LL807__A 1 Channel Full Duplex Audio on Fibre. In metal enclosure.

LL807__ 1 Channel Duplex Audio on Fibre. PCB Card.



1 - Channel Voice on Fibre Interface (bi-directional 2Fibre). Can be configured for 2W or 4W operation. Card only rack mount to fit in 19 rack.

WORKS WITH



LL807



Brochure

User Manual

Application Note

Text Box:    LL8071R           1 Channel 1 direction Audio on Fibre Receiver. In plastic enclosure.



1 - Channel Voice on Fibre Interface Receiver. To complement the 1 channel transmitter. Line audio output. Operating from 12VDC power supply.

WORKS WITH



LL8071T, LL807



Brochure

User Manual

Application Note

Text Box: ANALOG VIDEO/DATA

Our analog Video / Data systems incorporate facilities for Pan / Tilt / Zoom control of cameras. Data can be sent from the control room side to the camera using RS422 or RS485 control, baud rates of up to 19kb/s can be used. The units comes in a single point to point configuration or multiple point to card frame solution, the LL8023 is a 2 channel card that fits in a card frame and controls the data of 2 cameras and receives the video of 2 cameras. Up to 20 channels with PTZ control can be accommodated in 1 card frame. Products can be selected for Multi Mode or Single Mode Fibre.





LL8021 Single - Channel Video Transmitter & PTZ Data Receiver on 2 Fibres.



Single - Channel Video Transmitter and Data Receiver on 2 Fibres. In Plastic enclosure. Requires 12Vdc Power Supply.

WORKS WITH



LL8023, LL802 + LL422, LL803R



Brochure

User Manual

Application Note

LLD8021__A Single - Channel Video Transmitter & PTZ Data Receiver on 2 Fibres. Din Rail Mount!



Single - Channel Video Transmitter and Data Receiver on 2 Fibres. Din enclosure with 220VAC Power Supply. Din Rail Mount.

WORKS WITH



LL8023, LL802 + LL422, LL803R

Brochure

User Manual

Application Note

Text Box:    LL8022__A        1 - Channel Video Receiver & Data Transmitter on 2 Fibres. Din Rail Mount!



1 - Channel Video Receiver & Data Transmitter on 2 Fibres Din rail mount. 220VAC Power Supply built in.

WORKS WITH



LL8021

Brochure

User Manual

Application Note
