Digitally encoded Video and Data on Fibre.
Fibre is the most reliable means of transmission. Interference from Lightning, Electric fences etc. is nearly eradicated. This is the highest quality of Video transmission. There is no compression or degradation of the signal no matter what the distance of transmission. The normal maximum distance is 30km, however special versions can be configured to reach further distances. Digital video systems are superior due to the technology used. The Video Audio and Data is converted into a digital communication string and then sent over the fibre. On the receive side it is converted back to Video, Audio and Data again. There is no degradation of the signal quality and therefore a crisp clear signal is received. These units come in single and multiple channels , 4, 8 up to 64 channels can run on one fibre. This technology is suitable for a vast range of applications. It is used in mines , shopping centers and on airports city centers and is ideal for security applications. Picture quality is excellent. The Fibre range is up to 3km on Multi Mode and 30km on Single Mode. Longer distances can also be accommodated with purpose built units. Products can be selected for Multi Mode or Single Mode Fibre. |
|
LL800S — 3U 19” Card Frame for CCTV Video/Voice/Data on Fibre System. |
|
3U 19” Card frame for CCTV Video/Voice/Data on Fibre System. Frame & 220Vac PSU for 6 cards. |
|
WORKS WITH
LL809R, LL803T, LL8422, LL8023 |
|
Brochure User Manual Application Note |
|
LL8002D — 3U 19” Card Frame for CCTV Video/Voice/Data on Fibre System. |
|
3U 19” Card frame for CCTV Video/Voice/Data on Fibre System. Frame & 2x 220Vac PSU for 12 cards. |
|
WORKS WITH
LL809R, LL803T, LL8422, LL8023 |
|
Brochure User Manual Application Note |
|
DIGITALY ENCODED VIDEO ON FIBRE |
|
LLT801T — Single Channel Digitally encoded Video Transmitter. |
|
Single channel digitally encoded video transmitter. Small size, Metal enclosure. Operating from 12VDC Power supply. Operating on one fibre. |
|
WORKS WITH
LLT801R
|
|
Brochure User Manual Application Note |
|
LLT801R — Single Channel Digitally encoded Video Receiver. |
|
Single channel digitally encoded video Receiver. Small size, Metal enclosure. Operating from 12VDC Power supply. Operating on one fibre. |
|
WORKS WITH
LLT801T
|
|
Brochure User Manual Application Note |
|
LLT901T — Single Channel Digitally encoded Video, Data and Contact Transmitter. |
|
Single channel digitally encoded Video with Data and Contact transmitter. Small size, Metal enclosure. 12VDC Power supply. Operating on one fibre. |
|
WORKS WITH
LLT901R
|
|
Brochure User Manual Application Note |
|
LLT901R — Single Channel Digitally encoded Video, Data and Contact Receiver. |
|
Single channel digitally encoded Video with Data and Contact Receiver. Small size, Metal enclosure. Operating from 12VDC Power supply. Operating on one fibre. |
|
WORKS WITH
LLT901T
|
|
Brochure User Manual Application Note |
|
LLT908T — 8 Channel Digitally encoded Video, Data, Audio and Contact Transmitter. |
|
8 - channel digitally encoded Video, Data, Audio and Contact Transmitter. Metal enclosure. Operating from 12VDC Power supply. Operating on one fibre. |
|
WORKS WITH
LLT908R
|
|
Brochure User Manual Application Note |
|
LLT908R — 8 Channel Digitally encoded Video, Data, Audio and Contact Receiver. |
|
8 - channel digitally encoded Video, Data, Audio and Contact Receiver. Metal enclosure. Operating from 12VDC Power supply. Operating on one fibre. |
|
WORKS WITH
LLT908T
|
|
Brochure User Manual Application Note |
|
MULTY CHANNEL DIGITALLY ENCODED VIDEO ON FIBRE |
|
LLT901R - Single Channel units available in card frame mount. |
|
Single channel digitally encoded Video, Data, Audio and Contact cards to fit 5U - 19” card frame. |
|
WORKS WITH
LLT901T
|
|
Brochure User Manual Application Note |
