VIDEO ON  IP & IP ON FIBRE

   LLUA004          — 4 Channel Video sever.



4 Channel Analog Video Server. This unit converts the analog signals from the cameras to a IP standard signal.

WORKS WITH



Any Analog Video Camera



Brochure

User Manual

Application Note

   LLUA001CAM    — 3 Mega Pixel Security Camera.



3 Mega Pixel outdoor IP camera, With motorized Zoom lens.

WORKS WITH



IP Digital recorder, PC

Brochure

User Manual

Application Note

   LLUA002CAM    — 3 Mega Pixel Security PTZ Camera.



3 Mega Pixel outdoor IP camera, With PTZ control.

WORKS WITH



IP Digital recorder, PC

Brochure

User Manual

Application Note

   LLUA003CAM    — 3 Mega Pixel Security BOX Camera.



3 Mega Pixel IP Box camera, With motorized Zoom lens.

WORKS WITH



IP Digital recorder, PC

Brochure

User Manual

Application Note

   LLF102               — 2 Channel Media converter.



2 channel single link Media to Fibre converter. 10/100.

One fibre connection.

WORKS WITH



IP Systems

Brochure

User Manual

Application Note

   LLF1004N                 — 4 Channel Media converter network arrangement.



4 channel Media to Fibre converter. 10/100/1000.

Drop and insert fibre arrangement.

WORKS WITH



IP Systems

Brochure

User Manual

Application Note



Video on IP



Video on IP opens up a brand new avenue of opportunities. Although the bandwidth requirement of such a system is very demanding the advantages are numerous.

First of all it is not necessary to discard the existing standard CCTV video system, it can be incorporated in to an IP system using a video server. Please see detail below.



4 channel Analogue video to IP server.

IP OUT to PC monitor system.



Analogue cameras.                                      Media converters.



For ultimate performance the IP system can be rolled out on Fibre.

The biggest difference of the IP system is that it is now possible to use High resolution cameras providing much more detail of the security picture. Standard analog video cameras are limited to the line & frame type video signal. The best resolution at present is 900lines and 60 frames/second. Although this gives a realistic reproduction of fast movement the quality of the picture is poor. With IP cameras resolutions of 4 times that of analogue cameras is easily achievable.

We at ADD regard the IP as the high end video monitoring system. We therefore offer only high quality equipment for use on IP networks. For ultimate performance the IP system can be rolled out on Fibre.

Note that it is advisable not to share the IP video monitoring system with other data on the network. A separate network is recommended.

Another advantage of such a system is the ease of connecting to the Internet cloud.
