Data on Fibre.



Fibre is the most reliable means of transmission. Interference from Lightning, Electric fences etc. is nearly eradicated.

This is the highest quality of Data transmission. Data is transferred with the highest accuracy over fibre. There is no degradation of the signal no matter what the distance of transmission. The normal maximum distance is 30km, however special versions can be configured to reach further distances. Average link distances vary from 100m to 3km.

The units come in single and multiple channels and caters for various standards, such as  RS232, RS422, RS485, USB, X.21, CAN and many more.

Applications for use are control of switch gear, Access control, gate control, profibus and many more.

Products can be selected for Multi Mode or Single Mode Fibre. Single or duel fiber is used depending on the application. Ring networks with redundancy can be configured.

Text Box:

   LLU400          — 16 Channel RS232 digitally encoded Data point to point unit.



16 —Channel RS232 data on Fibre unit. Metal enclosure. Operating from 220VAC Power. Multi Mode and Single mode Fibre. Distances 3 to 12 km is easily achievable.

WORKS WITH



LLU400



Brochure

User Manual

Application Note

MULTY CHANNEL DIGITALLY ENCODED DATA ON  FIBRE

   LL2004          — 4 x E1 - G703 transmission unit.

4 x E1 G703 transmission unit. Operating form built in 220VAC power supply. Supervisory indications and alarm contact. In metal enclosure. Multi and Single mode Fibre. Distances 3 to 12 km are easily achievable. 120E balanced and 75E BNC connections.

WORKS WITH



LL2004

Brochure

User Manual

Application Note

SINGLE CHANNEL DATA ON  FIBRE

   LLA422          — Single Channel RS232,RS422,RS485 on Fibre.

Single channel RS232,RS422,RS485 data on Fibre unit. Small size, Plastic enclosure. Operating from 12VDC Power supply. Multi Mode and Single mode Fibre. Distances 3 to 12 km are easily achievable.

WORKS WITH



LLA422, LL425USB

Brochure

User Manual

Application Note

   LL2000          — E1 - 30 channel G703 transmission unit.

Single E1 30 channel G703 transmission unit. Operating form built in 220VAC power supply. Supervisory indications and alarm contact. In metal enclosure. Multi and Single mode Fibre. Distances 3 to 12 km are easily achievable. 120E balanced and 75E BNC connections.

WORKS WITH



LL2000

Brochure

User Manual

Application Note

   LL2100          — X21 interface transmission unit.

Single channel X21 transmission unit. Sync operation up to 64kbps. Operating form built in 220VAC power supply. With alarm contact. In metal enclosure. Multi and Single mode Fibre. Distances 3 to 12 km are easily achievable.

WORKS WITH



LL2100

Brochure

User Manual

Application Note
